Terex Manlift Specifications
Terex is a Westport, Connecticut company that specializes in making in manufacturing construction machines. Machines such as boom lifts, aerial lifts and manlifts. These kinds of equipments are designed to facilitate access to hard to reach places, large equipment, buildings and roofs, among other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration or also called OSHA refers to a power-driven endless belt. This belt only moves in one direction and includes handholds or platforms or steps that are connected to the unit to be able to move employees from every floor.
TB85
The TB85 man lift by Terex offers a max working height at 91 feet. The max height of the platform reaches 85 feet, while the maximum width of the model is 8.5 feet. The TB85 has dimensions measuring 9 inches wide and 9 feet, 1-inch high by 36 feet. This model provides a reach of seventy feet. The TB85 has a boom angle below horizontal measures at -14 degrees and above horizontal reaching 75 degrees.
Terex TB100
The maximum height of Terex's TB100 man lift is 106 feet and the platform's maximum height is 100 feet. The TB100 when stowed away, is approximately 9 feet high by 8.5 feet wide by 8 feet. The maximum width of the unit is 8 feet, 1 1/2 inches. The boom angle above horizontal is 75 degrees and below horizontal is 14 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The Terex TB110 man lift reaches a max height of 100 feet, while the max working height measures at 116 feet. The model is 8 feet wide x 9 feet, 4 inches high The TB110 provides a maximum width of 8 feet and a horizontal reach of 67 feet. This particular model has a boom angle of 75 degrees above horizontal plus ten degrees articulating. It measures -105 degrees articulating and below horizontal it is -14 degrees.
